ASM20004-IN-1 MICRO-INVERTER
2000 W · 4-in-1
A four-module micro-inverter for residential and light-commercial rooftops. Four independent MPPT channels feed one 230 V AC output, cutting AC cabling and per-panel hardware count while keeping module-level tracking and visibility.
4 PV modules2000 W ACQuad MPPTIP67
SPECIFICATIONS
PV inputs4 (independent MPPT)
MPPT voltage range16 – 60 V
Max input voltage65 V
Max input current16 A
Rated AC output2000 W
AC voltage / frequency230 V · 50 / 60 Hz
Rated AC current9.1 A
Ingress protectionIP67
Operating temperature−40 … +65 °C
Protective classClass I
DC connectorsMC4
CertificationCE · further approvals [confirm]
ELECTRICAL VALUES TRANSCRIBED FROM PRODUCT NAMEPLATES · [CONFIRM] ITEMS AWAIT OFFICIAL DATASHEET DATA
